900-82888-0050-000 NVIDIA Jetson AGX Xavier 64 GB Compute Module
SKU: 71000NVIDIA® Jetson AGX Xavier
- 64GByte version Model: 900-82888-0050-000
512-Core NVIDIA Volta GPU with Tensor Cores
(2x) NVDLA Engines
8-Core ARM v8.2 64-Bit Carmel CPU
64GB 256-bit LPDDR4x 136.5GB/s
32 GB eMMC 5.1 Flash Storage
7-Way VLIW Vision Accelerator Processor
The Jetson AGX Xavier 64GB module makes AI-powered autonomous machines possible, running in as little as 10W and delivering up to 32 TOPs. Customers can leverage the 64GB memory to store multiple AI models, run complex applications, and enhance their real time pipelines. As part of the world’s leading AI computing platform, it benefits from the rich set of NVIDIA AI tools and workflows, enabling developers to train and deploy neural networks quickly. Jetson AGX Xavier 64GB is supported by NVIDIA JetPack SDK, which can help you save development effort and expense.
| Download | |||
| Firmware | |||
If there is no stock, lead times may vary. Please ask the sales team: sales@auvidea.com.
Available on backorder
Features
Module
512-Core NVIDIA Volta GPU with Tensor Cores
(2x) NVDLA Engines
8-Core ARM v8.2 64-Bit Carmel CPU
64GB 256-bit LPDDR4x 136.5GB/s
32GB eMMC 5.1 Flash Storage
7-Way VLIW Vision Accelerator Processor
Power
Voltage input 5 V, 9 V~20 V
Module Power: 10 W~30 W
Environment
Operating temperature: -25 C to 80 C measured on the TTP surface
Storage temperature: -25 C to 80 C
Humidity: 95% RH, -10 C to 65 C (non-operational)
Vibration: 5 G RMS 10 to 500 Hz (random/ sinusoidal)
Shock: 50 G, half sine 11 ms duration
Technical information
GPU NVIDIA Volta architecture with 512 NVIDIA CUDA cores and 64 Tensor cores
22 TOPS (INT8)
DL Accelerator 2x NVDLA 10 TOPS (INT8)
CPU 8-core NVIDIA Carmel Arm v8.2 64-bit CPU
8MB L2 + 4MB L3
Memory 64GB 256-bit LPDDR4x
136.5GB/s
Display Three multi-mode DP 1.2a/e DP 1.4/HDMI 2.0 a/b
Storage 32GB eMMC 5.1
Vision Accelerator 2x PVA
Video Encode 4x 4K60 | 8x 4K30 | 16x 1080p60 | 32x 1080p30 (H.265)
4x 4K60 | 8x 4K30 | 14x 1080p60 | 30x 1080p30 (H.264)
Video Decode 2x 8K30 | 6x 4K60 | 12x 4K30 | 26x 1080p60 | 52x 1080p30 (H.265)
4x 4K60 | 8x 4K30 | 16x 1080p60 | 32x 1080p30 (H.264)
CSI Up to 6 cameras (36 via virtual channels)
16 lanes MIPI CSI-2
D-PHY 1.2 (up to 40Gbps)
C-PHY 1.1 (up to 62Gbps)
UPHY 8x PCIe Gen4
3x USB 3.1
Single Lane UFS
Other USB 2.0
UART, SPI, CAN, I2C, I2S, DMIC & DSPK, GPIOs
Networking 10/100/1000 BASE-T Ethernet
Power 10W | 15W | 30W
Mechanical 100mm x 87mm
699 pin Molex Mirror Mezz Connector
Integrated Thermal Transfer Plate
