900-82888-0040-000 NVIDIA Jetson AGX Xavier 32 GB Compute Module

SKU: 71002

 983,00

Plus 19% VAT
Delivery Time: ca. 48 hours

NVIDIA® Jetson AGX Xavier

  • 32GByte version Model: 900-82888-0040-000

512-Core NVIDIA Volta GPU with Tensor Cores
(2x) NVDLA Engines
8-Core ARM® v8.2 64-Bit Carmel CPU
32GB 256-Bit LPDDR4x|136.5GB/s
32 GB eMMC 5.1 Flash Storage
7-Way VLIW Vision Accelerator Processor

The NVIDIA Jetson AGX Xavier delivers up to 32TOPS of accelerated computing capability in a compact form factor consuming under 30 watts.

This advanced system-on-module is powered by the NVIDIA Xavier SoC, it is designed for cost-effective and performance-driven autonomous machine applications. Heterogeneous accelerated computing architecture delivers advanced compute performance and allows AI at the edge. It comes with integrated memory, storage, power management, and an innovative thermal design to enable faster time to market. The Jetson AGX Xavier is able to run modern AI workloads and solve problems in optical inspection, manufacturing, robotics, logistics, retail, service, agriculture, smart cities, and healthcare.

Jetson AGX Xavier is supported by the NVIDIA JetPack SDK, which includes board support package (BSP), Linux OS, NVIDIA CUDA, cuDNN, and TensorRT software libraries for deep learning, computer vision, GPU computing, multimedia processing, and much more. It’s also supported by the NVIDIA DeepStream SDK, which delivers a complete toolkit for real-time situational awareness through intelligent video analytics (IVA) and NVIDIA Isaac SDK, which delivers a software toolkit for robot development. These helps boost performance and accelerate software development, while reducing development cost and effort.

Download
´

204 in stock (can be backordered)




Technical Specifications
GPU 512-Core Volta GPU with Tensor Cores
DL Accelerator (2x) NVDLA Engines
CPU 8-Core ARM v8.2 64-Bit CPU, 8 MB L2 + 4 MB L3
Memory 32 GB 256-Bit LPDDR4x | 137 GB/s
Display HDMI 2.0, eDP1.4, DP HBR3
Storage 32 GB eMMC 5.1 200MHz (HS400)
Vision Accelerator 7-Way VLIW Vision Processor
Video Encode (2x) 1000 MP/s (H.265)
(2x) 980 MP/s (H.264)
(2x) 600 MP/s (VP9)
Video Decode (2x) 1500 MP/s (H.265)
(2x) 1000 MP/s (H.264, VP9)
CSI (16x) CSI-2 Lanes
UPHY 3 x USB 3.1, 4 x USB 2.0,  PCIe: x8, x4, x2,  5 x UART, 3 x SPI, 5 x I2C, 2 x CAN
Other UART, SPI, CAN, I2C, I2S, DMIC, GPIOs
Connectivity 10/100/1000 GbE (RGMII)
Size 100 mm x 87 mm
Weight 274 gr
Mechanical 699 pin connector | integrated thermal transfer plate (heat spreader)
Carrier boards X200, X220 and X220-LC

order code: 71002
