This board is based around the capabilities of the PAB (Pixhawk Autopilot Bus Standard) implemented in our JNX110 carrier board, to enable easy and space efficient installation of flight controllers in different use cases.

The power in supports reverse voltage protection and an inrush current limitation to minimize mishaps during setup.

All standard PX4 autopilot functions are supported, including an STM32F103 I/O controller for reliable and low-latency signal handling.

• size: 55mm x 55mm
• weight (w/o flight controller): tbd
• NXP extensions: FMU I/O 9-12, CAN 3
• power in: 12V (reverse voltage protection, inrush current limitation)
