900-13701-0040-000 NVIDIA Jetson AGX Orin 32GB Compute Module

SKU: 71012


Plus 19% VAT
Delivery Time: available for immediate delivery

NVIDIA­­ Jetson AGX Orin 32GB compute module 900-13701-0040-000

Bring your next-generation products to life with one of the world’s most powerful AI computers for energy-efficient autonomous machines. With up to 275 TOPS and 8x the performance of the last generation for multiple concurrent AI inference pipelines and support for multiple high-speed sensor interfaces, NVIDIA Jetson Orin™ modules provide the ideal solution for a new age of robotics.

97 in stock (can be backordered)


Jetson AGX Orin 32GB Module Technical Specifications
AI Performance: 200 TOPS (INT8)
GPU: NVIDIA Ampere architecture with 1792 NVIDIA® CUDA® cores and 56 Tensor Cores
Max GPU Freq: 939 MHz
CPU: 8-core Arm® Cortex®-A78AE v8.2 64-bit CPU 2MB L2 + 4MB L3
CPU Max Freq: 2.2 GHz
DL Accelerator: 2x NVDLA v2.0
DLA Max Frequency: 1.4 GHz
Vision Accelerator: PVA v2.0
Memory: 32GB 256-bit LPDDR5 204.8 GB/s
Storage: 64GB eMMC 5.1
CSI Camera: Up to 6 cameras (16 via virtual channels*) 16 lanes MIPI CSI-2: D-PHY 2.1 (up to 40Gbps) | C-PHY 2.0 (up to 164Gbps)
Video Encode: 1x 4K60 | 3x 4K30 | 6x 1080p60 | 12x 1080p30 (H.265) H.264, AV1
Video Decode: 1x 8K30 | 2x 4K60 | 4x 4K30 | 9x 1080p60| 18x 1080p30 (H.265)
H.264, VP9, AV1
UPHY: Up to 2 x8, 1 x4, 2 x1 (PCIe Gen4, Root Port & Endpoint) 3x USB 3.2 Single lane UFS
Networking: 1x GbE 4x 10GbE
Display: 1x 8K60 multi-mode DP 1.4a (+MST)/eDP 1.4a/HDMI 2.1
Other I/O: 4x USB 2.0 4x UART, 3x SPI, 4x I2S, 8x I2C, 2x CAN, DMIC & DSPK, GPIOs
Power: 15W – 40W
Mechanical: 100mm x 87mm 699-pin Molex Mirror Mezz Connector Integrated Thermal Transfer Plate
